Clymer

Harley-Davidson FLS-FXS Evolution, Evo Softail, Fat Boy (1984-1999) Clymer Online Manual

$51.95

Available Formats
  • Access using your Haynes account
  • Available to use immediately
  • No shipping fees
  • Full coverage on: Bad Boy 1984-1999, Softail Custom 1984-1999

Description

With an online Clymer motorcycle repair manual, you'll get all of the trusted Clymer content but with added features to help you get the job done right.

  • Harley Davidson Bad Boy 1984-1999
  • Harley Davidson Softail Custom 1984-1999

Every Clymer manual contains hundreds of original photographs and illustrations developed from a complete disassembly and assembly of a motorcycle - choosing an online lets you zoom in on the detail, so you can work quickly, and with confidence. This, in addition to extensive research, allows Clymer to achieve an unmatched level of detail, accuracy and clarity.

More Information

  • Table of Contents

    • Testing electrical components / Emergency troubleshooting / Engine noises / Electrical problems / Excessive vibration / Specifications
    • Routine safety checks / Maintenance schedule intervals / Periodic lubrication / Engine oil and filter change / oil tank flushing / Transmission oil chaneg / Front fork oil change (non-Springer models) / Speedometer cable lubrication / Primary chain lubrication / Drive chain lubrication / Periodic maintenance / Drive chain inspection and adjustment / Final drive belt inspection and adjustment / Clutch adjustment / Clutch diaphragm spring adjustment (1985-189 wet clutch) / Throttle cable adjustment / Choke cable adjustment / Enrichener/Choke cable adjustment / Air cleaner service / Tune-up / Compression test / Spark plugs / Breakerless ignition service / Carburetor adjustments / Storage / Specifications
    • Removal installation / Rocker arm cover / Cylinder head / Valves and components / Cylinder / Pistons and rings / Pushrods / Tappets and tappet guides / Oil pump / Oil filter mount / Gearcase cover and timing gears / Crankcase and crankshaft / Engine break-in / Specifications
    • Dry clutch (early 1984 FXST) / Wet clutch / Primary chain / Compensating sprocket / Primary chain case / Electric starter drive (1984-1988) / Starter jackshaft (1989-on) / Specifications
    • Shifter cover / Shift forks / Kickstarter and starter clutch / Side cover ( electric start ) / Shifter adjustment / Specifications
    • Production gears (1994 models) / Shift cam assembly / Shift forks / Transmission / Transmission case / Transmission side cover (1987-on) / Adjustments / Specifications
    • Air cleaner / Carburetor / Carburetor rejetting / Throttle and idle cable replacement / Choke enrichener cable / Fuel tanks / Fuel shutoff valve / Exhaust system / Emission control (1985-1991 California models) / Evaporative emission control system (1992-on California models) / Specifications
    • Battery / Charging system / Ignition system / Ignition coil / Starter / Starter solenoid (1984-1988) / Starter solenoid (1989-1990) / Starter solenoid (1991-on) / Starter relay / Switches / Horn / Turn signal module (1991-on) / Circuit breakers / Specifications
    • Front wheel / Front hub / Rear wheel / Rear hub / Driven sprocket assembly / Drive chain / Drive belt / Laced wheels / Cast or disc wheels / Wheel balance / Tire repairs / Specifications
    • Handlebar / Steering head and stem / Steering head bearing race / Steering adjustment / Front fork / Specifications
    • Steering adjustment / Specifications
    • Rear shock absorbers / Rear swing arm / Specifications Brake pads / Brake caliper / Master cylinder / Disc brake / Bleeding the system / Specifications
    • Jiffy stand (sidestand) / Footpegs / Front fender (1993-on FXSTS) / Front fender (all other models) / Rear fender / Saddlebags (1993-on) / Frame / Specifications
    • Ignition system / Routine safety checks / Periodic maintenance / Breakerless ignition service (1995-1999) / Engine removal (1996-1999) / Wet clutch (1998-1999) / Clutch shell, compensating sprocket and primary drive chain (1998-1999) / Evaporative emission control system (1996-1999) / Battery / Ignition system (1995-1999) / Lighting system (1995-1999) / Switches (1997-1999) / Turn signal module (1997-1999) / Front wheel (1996-1999) / Front hub (1996-1999 Springer models) / Rear hub (1997-1999) / Springer front fork (1997-1999) / Front brake caliper (1997-1999 FLSTS) / Front master cylinder (1997-1999) / Front fender (1995-1999 FLSTS)
    • COLOR WIRING DIAGRAMS,Models covered:,1986 1987 1988 1989 1990 HARLEY-DAVIDSON FLST,1987 1988 1989 1990 1991 1992 1993, 1993 HDI 1994 1995 1996 1997 1998 1999 HARLEY-DAVIDSON FLSTC,1990 1991 1992 1993, 1993 HDI 1997 1998 1999 HARLEY-DAVIDSON FLSTF,1993, 1993 HDI, 1994 1995 1996 HARLEY-DAVIDSON FLSTN,1993, 1997 1998 1999 HARLEY-DAVIDSON FLSTS,1984 1985 1986 1987 1988 1989 1990, 1999 HARLEY-DAVIDSON FXST,1999 HARLEY-DAVIDSON FXSTB,1985 1986 1987 1988 1989 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 HARLEY-DAVIDSON FXSTC,1993 1994 1995 1996 HARLEY-DAVIDSON FXSTF,1988 1989 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 HARLEY-DAVIDSON FXSTS,1995 1996 1997 1998 HARLEY-DAVIDSON FXSTSB,

Benefits

  • Written from Hands-On Experience
    Follow insights from a complete machine teardown

    Written from Hands-On Experience

    Take on tasks with insights from a full vehicle teardown

  • Clear Step-by-Step Instructions & Photos
    Make every repair and service task easy to execute
  • Work with Confidence
    Notes, cautions and warnings guide you through each procedure
  • Cut-Back on Costs
    Learn the essential skills to help you work independently
  • Locate Content Quickly
    A detailed index and reference data section helps you find what you need
  • Color Wiring Diagrams
    Translate complex work with easy-to-follow schematics
