Time
10 minutes
Difficulty
Air filter location
First, undo the circular clip on the air intake - use a 7mm socket
Now release the air intake
Undo the 4 Phillips retaining fixings on the air filter body
Carefully separate and lift away the air filter body
View of the air filter cover
Air filter in position
Lift out the air filter
Clean off any debris on the surface of the filter. Replace with a new filter if heavily contaminated
Check air filter box for debris. Clean out if required. Replace the air filter
Reassemble the air filter housing
